NI 780587-40 | NI PXIe-2540, RF matrix, 8x9

Manufacturer number: 780587-40

NI 780587-40
Delivery time upon request

€4,440.00

or choose one of the following options:
Product downloads Product inquiries
Highlights Technical Data Documents / Downloads Description Related Articles

780587-40 | NI PXIe-2540, RF matrix, 8x9.

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Documents & Downloads

Catalog
pdf | 5.12 MB
Brochure
pdf | 2.74 MB
Overview
pdf | 1.35 MB
Configuration guide
pdf | 1.88 MB

Description

780587-40 | NI PXIe-2540, RF matrix, 8x9

The PXI ‑ 2540 is a matrix switch for routing high frequency signals. Thanks to a non-blocking design, each row or column within the switching matrix can be controlled at the same time and the flexibility of the test system can be maximized. Isolation relays on the module separate unused components of the switch matrix to ensure high frequency performance and high isolation. The PXIe ‑ 2540 has high channel density and bandwidth, making it ideal for routing signals between digitizers, function generators, and other RF generators and analyzers.

Product features:

  • Bus type: PXIe
  • Crosspoints: 72
  • Number of rows: 8
  • Number of columns: 9
  • Switching bandwidth: 350 MHz
  • Characteristic impedance: 50 ohms
  • Relay type: reed relay
  • Maximum switching voltage (AC): 42.4 Vs
  • Maximum continuous current (AC): 0.5 A
  • Scanning frequency: 100 cycles / s
