NI 779010-01 | NI 9435 Sinking / sourcing digital input module with 4 channels (250 VAC / DC, 3 ms) with screw connections

Name: 779010-01 | NI 9435 Sinking / sourcing digital input module with 4 channels (250 VAC / DC, 3 ms) with screw connections
Brand: NI
SKU: 779010-01
Price: 360.0 EUR
Availability: OutOfStock

Manufacturer number: 779010-01

Delivery time upon request

€360.00

or choose one of the following options:

Product inquiries

779010-01 | NI 9435 Sinking / sourcing digital input module with 4 channels (250 VAC / DC, 3 ms) with screw connections.

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Bustype:	C Series
Connection type front:	10-Pin, Weiblich Schraubanschluss
Isolation of the digital I/O:	250 Veff Isolierung Kanal gegen Masse
Logic level and range:	240 VDC, 240 VAC, 120 VDC, 120 VAC, 96 V, 12 V, 48 V, -250.0V - 250.0V, 72 V, 24 V, 5 V
Logic level of the digital I/O:	240 VAC, 120 VDC, 120 VAC, 96 V, 12 V, 48 V, 240 VDC, 72 V, 24 V, 5 V
Module width:	1
Number of bidirectional digital channels:	0
Number of digital inputs:	4
Number of digital outputs:	0
Protectively coated:	No
Spannungsmessbereich DI:	-250 V bis 250 V
With case:	Yes

Description

779010-01 | NI 9435 Sinking / sourcing digital input module with 4 channels (250 VAC / DC, 3 ms) with screw connections

The NI ‑ 9435 uses industrial logic levels and signals so it can be connected directly to a wide variety of industrial switch modules, converters, and other devices. Each channel is compatible with signals from ± 5 VDC to 250 VDC and 10 VAC to 250 VAC and includes overvoltage protection between input channels and ground as well as an LED status display. The NI ‑ 9435 is a correlated digital module, so it enables correlated operations, triggers, and synchronization when installed in a CompactDAQ chassis.

Product features:

Number of pure digital input channels: 4
Number of pure digital output channels: 0
Number of bidirectional digital channels: 0
Logic level of the digital I / O: 5V 12V 24V 48V 72V 96V 120 VDC 240 VDC 120 VAC 240 VAC
Maximum update rate: 3 ms
Current flow direction: Current-sinking input Current-supplying input
Isolation of the digital I / O: 250 Veff Isolation of the channel from ground
Connection type front: screw connection
Protective coating: no
With housing: yes
Supported hardware platform: CompactDAQ, CompactRIO
