NI 779003-01 | NI 9474, high-speed power sourcing digital output module, 8 channels, 24 V, 1 µs

Name: 779003-01 | NI 9474, high-speed power sourcing digital output module, 8 channels, 24 V, 1 µs
Brand: NI
SKU: 779003-01
Price: 560.0 EUR
Availability: OutOfStock

Manufacturer number: 779003-01

Delivery time upon request

€560.00

or choose one of the following options:

Product inquiries

779003-01 | NI 9474, high-speed, high-speed digital output module, 8 channels, 24 V, 1 µs.

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Bustype:	C Series
Connection type front:	10-Pin, Weiblich Schraubanschluss
Isolation of the digital I/O:	250 Veff Isolierung Kanal gegen Masse
Logic level and range:	24 V, 12 V, 5.0V - 30.0V
Logic level of the digital I/O:	12 V, 24 V
Module width:	1
Number of bidirectional digital channels:	0
Number of digital inputs:	0
Number of digital outputs:	8
Protectively coated:	No
With case:	Yes

Description

779003-01 | NI 9474, high-speed power sourcing digital output module, 8 channels, 24 V, 1 µs

The NI ‑ 9474 uses industrial logic levels and signals so it can be connected directly to a wide variety of industrial switch modules, converters, and other devices. Each channel is compatible with signals from 5 V to 30 V, offers overvoltage protection against interference between the output channels and ground, and has an LED status display. The NI ‑ 9474 is a correlated digital module, so it enables correlated operations, triggering, and synchronization when installed in a CompactDAQ chassis.

Product features:

Number of pure digital input channels: 0
Number of pure digital output channels: 8
Number of bidirectional digital channels: 0
Logic level of the digital I / O: 12 V 24 V.
Maximum update rate: 1 µs
Direction of current flow: output supplying current
Isolation of the digital I / O: 250 Veff Isolation of the channel from ground
Connection type front: screw connection
Protective coating: no
With housing: yes
Supported hardware platform: CompactDAQ, CompactRIO
