HUBERT A1020-200-100 | High-frequency power amplifier, 100 kHz - 100 MHz, 200 W (10200070)

Manufacturer number: 10200070

A1020-200-100
Delivery time upon request

€9,700.00

or choose one of the following options:
Request a quote Product inquiries Request education-price
Highlights Technical Data Description Related Articles

HUBERT A1020-200-100 | RF broadband power amplifier 100 kHz - 100 MHz / 200 W.

  • Frequenzgang: 100 kHz - 100 MHz
  • Lineare Ausgangsleistung: 200 W
  • Universell einsetzbarer HF-Verstärker mit 50 Ω Ein-/Ausgang
  • Ultra breitbandiger Frequenzgang über mehrere Dekaden
  • Hohe Linearität ermöglicht gute Signaltreue mit allen Modulationsarten
  • Geringe Verzerrungen für saubere Testsignale
  • Hohe Verstärkungs-Stabilität über der Temperatur
  • Optimales Kühlkonzept ermöglicht möglichst geringe Geräuschentwicklung bei kleinem Gewicht
  • Hocheffiziente Stromversorgung mit einem Leistungsfaktor nahe 1 und universellem Weitbereichseingang.
  • Monitorausgang parallel zum Verstärkerausgang zur Überwachung des Testsignals
  • Interlock Anschluss für sichere Prüfaufbauten
  • Stromversorgung: Weiteingangsbereich 88 - 264 VAC / 47 - 63 Hz (weltweiter Einsatz möglich)
  • Maße: B 448 x H 153,6 x T 546 mm
  • Gewicht: 14,5 kg

Anwendungen:

  • Allgemeine Anwendungen in Forschung, Entwicklung und Prüffeld
  • EMV Prüfungen (z.B. mit CDNs, Koppelzangen, Antennen)
  • Funktechnik
  • Materialprüfungen
  • Medizintechnik
  • Bauteiletests
  • Lasertechnik
  • Plasmatechnik

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Description

A1020-200-100 | High-frequency power amplifier, 100 kHz - 100 MHz, 200 W (10200070)

The RF broadband power amplifiers of the A1020 family are robust Class A/AB amplifiers for EMC testing and general laboratory applications.

Stability under all load conditions occurring in practice, a wide frequency range, low distortion and a fair purchase price characterize these amplifiers.

Optimal cooling is ensured by the use of a high-performance heat sink with temperature-controlled fans. Sophisticated protective devices protect the hardware even under extreme load conditions and the devices are also available for rack mounting as an option.

Accessoires (1 product)

A1340-C1
HUBERT
A1340-C1
Isolation amplifier, 3 port, DC - 1.7 MHz, 20 V / µs (13400010)
Delivery time upon request
€2,000.00

Alternate products (5 products)

A1020-25-250
HUBERT
A1020-25-250
High frequency amplifier, 150 kHz - 250 MHz, 25 W (10200010)
Delivery time upon request
€4,700.00
A1020-75-400
HUBERT
A1020-75-400
High frequency amplifier, 100 kHz - 400 MHz, 75 W (10200030)
Delivery time upon request
€6,650.00
A1020-75-250
HUBERT
A1020-75-250
High frequency amplifier, 10 kHz - 250 MHz, 75 W (10200040)
Delivery time upon request
€6,650.00
A1020-180-400
HUBERT
A1020-180-400
High frequency amplifier, 1 MHz - 400 MHz, 180 W (10200050)
Delivery time upon request
€9,700.00
A1020-200-20
HUBERT
A1020-200-20
High-frequency power amplifier, 100 kHz - 20 MHz, 200 W (10200060)
Delivery time upon request
€9,700.00

About the Manufacturer

HUBERT
HUBERT
Dr. Hubert's portfolio includes power amplifiers, EMC interference generators, coupling networks for EMC testing and general laboratory applications. Dr. Hubert's products are manufactured in Germany and can also be modified in small quantities for special applications upon customer request.

In close cooperation with the University of Applied Sciences Bochum, Dr. Hubert combines future-oriented research and industrial application at the Technology Center Ruhr (TZR).
