GW Instek GSP-9330 | Clearance Spectrum Analyzer, 9 kHz - 3.25 GHz, LAN/USB/RS-232, AM/FM/ASK/FSK, -122 to +33 dBm (DT1205_1808_L)

Name: GSP-9330 | Clearance Spectrum Analyzer, 9 kHz - 3.25 GHz, LAN/USB/RS-232, AM/FM/ASK/FSK, -122 to +33 dBm (DT1205_1808_L)
Brand: GW Instek
SKU: DT1205_1808_L
Price: 4399.2 EUR
Availability: InStock

Manufacturer number: DT1205_1808_L

1 in stock. Ready to ship in 1 business day

€4,399.20

% €5,499.00 (20% saved)

or choose one of the following options:

Request a quote Product inquiries

Special item - GW Instek GSP9330 | Spectrum analyzer from 9 kHz to 3.25 GHz with integrated preamplifier and EMC pre-test function. (DT1205_1808_L).

Frequency range: 9 kHz to 3.25 GHz
Frequency resolution: 1 Hz
Frequency stability: 0.025 ppm and aging rate: 1 ppm
Resolution bandwidth: 1 Hz to 1 MHz (3dB), 6 dB EMI, filter: 200 Hz, 9 kHz, 120 kHz, 1 MHz
Fastest sweep: up to 204 μs
Sensitivity: -149 dBm/Hz (with preamplifier switched on)
DANL: -122 dBm (at 1 MHz to 2.7 GHz) or -116 dBm (at 2.7 to 3.25 GHz), each without Preamplifier
Three display types: spectrum, topographic and spectrographic
Display can be divided into 2 display areas
Color LCD display: Screen diagonal approx. 21 cm (8.4 inches) with 800 x 600 pixels
Menu fields are shown on the display
Integrated preamplifier (1 MHz to 3.25 GHz / 18 dB)
Integrated 50 dB attenuator
Integrated measurement sequence options
Integrated EMC pre-test measurement function with quasipeak or average EMI detection mode
Integrated AM, FM, ASK, FSK, and Binary FSK demodulation and analysis
Integrated measurement function of 1 dB point, harmonics, CHBW, OCBW, ACPR, SEM, TOI, CNR, CTB, CSO, N-dB bandwidth, noise marker, frequency counter, TDP, gated sweep
Remote control through free EMI measurement software SpektrumShot for PCs
DVI-I video output
Front-panel MicroSD slot
Rear-panel reference input and output, alarm output, trigger input, IF output, headphone output
Standard interfaces: LAN, USB, RS-232
Optional interface: GPIB
Optional: tracking generator
Optional: battery for mains-free operation
Mains voltage: AC 100 V to 240 V, 50 / 60 Hz, automatic detection
Standard accessories: power cable, calibration certificate, CD-ROM (with quick start guide, user manual, programming manual, SpectrumShot software for EMI measurements, SpectrumShot manual and IVI driver)
Dimensions: H 210 mm x W 350 mm x D 100 mm
Weight: 4.5 kg incl. all options
2 year warranty

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Device type:	Spectrum analyzer
Special item type:	Stock sale

Documents & Downloads

Datasheet

pdf | 1.67 MB

Description

GSP-9330 | Clearance Spectrum Analyzer, 9 kHz - 3.25 GHz, LAN/USB/RS-232, AM/FM/ASK/FSK, -122 to +33 dBm (DT1205_1808_L)

This cost-effective spectrum analyzer GSP-9330 with very strong performance data from GW Instek offers a bandwidth of 9 kHz to 3.25 GHz. With this analyzer, spectra can be recorded and evaluated very quickly - a spectrum sweep can be recorded within 204 µs, which means that modulation signals can be verified very quickly. Not only the fast sweep but also the signal demodulation functions are characteristic. In addition to the usual AM/FM demodulation and analysis, the GSP9330 can also analyze digital modulation types such as ASK/FSK (Amplitude Shift Keying / Frequency Shift Keying) and 2FSK (Binary FSK / Binary Frequency Shift Keying).

EMC (Electromagnetic Compatibility) and EMI (Electromagnetic Interference) are becoming increasingly important, as is EMS (Electromagnetic Susceptibility). This spectrum analyzer can also be used for such measurements during the ongoing development process. The device is equipped with the corresponding EMC pre-test functions for this purpose. The integrated solution procedures for these EMC pre-tests can significantly reduce product development times.

One of the features of this device is that the display can be split to show the results - for the topographical as well as the spectrographic display.

Please note: Special items may show signs of use. All special items have a 1-year guarantee. The item is subject to prior sale. The configuration of a special item cannot be changed.
