FLUKE 289 / FVF | Multimeter, set, 4 1/2 digits, 289, FlukeView Forms software and cables

Name: 289 / FVF | Multimeter, set, 4 1/2 digits, 289, FlukeView Forms software and cables
Brand: FLUKE
SKU: FLUKE-289/FVF/EUR
Availability: InStock

Manufacturer number: FLUKE-289/FVF/EUR

1 in stock. Ready to ship in 1 business day

On Request

or choose one of the following options:

Request a quote Product inquiries Request education-price

Fluke 289 / FVF | Multimeter, set, 4 1/2 digits, 289, FlukeView Forms software and cables

Large ¼ VGA display with a display range of 50,000 digits and white backlight. Results of several measurements can be shown simultaneously on the large display.
The logging function with trend display (TrendCapture) is an important tool for documenting target performance of your design, processes or systems. It is used for unattended monitoring while you are doing other tasks. The device displays measurements graphically as a single line for better detection of signal anomalies over a longer period of time and stores up to 10,000 measured values. With the integrated trend display function (TrendCapture), recorded measured values can be displayed graphically without the use of a PC. (Optional software and interface cable).
Record multiple measurements or continuously record data for more than 200 hours. This is particularly useful when determining the overall performance of a design or for unattended monitoring.
"I" info button / built-in help for measurement functions. Do you need information about a specific function? Simply select the function in question and press the "i" button.
Measuring function with low input impedance (LoZ). The measurement function with low input impedance prevents erroneous measurement values due to "phantom voltages". This mode is also recommended for checking for the presence or absence of voltage.
Low pass filter for precise voltage and frequency measurement on drive controls with adjustable speed and other electrical devices in which harmonics overlap the fundamental frequency.
50 Ω range: For measurements and comparisons of motor winding resistances, low-resistance measurements and other contact resistances. 50 Ω range with two measuring connections and with a resolution of 1 mΩ and a measuring current of 10 mA.
Saved measurements enable the naming and recall of measurements carried out in mobile use
Real-time clock: Allows automatic time marking of saved measured values
The measuring device, which can be retrofitted and expanded at the place of use, makes it possible to stay up to date and to use newly added functions as soon as they are available
Recording of events and trends: Used for troubleshooting intermittent problems and for displaying loads.
Multilingual user interface
Programmable buttons, scroll buttons, and simple navigation controls for access to secondary functions. You can also define custom ads.
Basic accuracy: 0.025% with DC voltage
AC bandwidth: 100 kHz
True effective measurement of AC voltage and current for precise measurements of complex signals or non-linear loads.
Measurement of up to 10 A (20 A for 30 seconds, 10 A continuous operation)
Capacity range: 100 mF
Temperature function
Relative value mode for subtracting the test lead resistance for low-resistance measurements or capacitance measurements
Peak value acquisition for recording short-term transients up to 250 µs
High quality test leads including alligator clips
Optical USB interface for easy transfer to the PC for documentation of measurement data with the FVF software (not included in the scope of delivery).
Navigation keys for quick selection of menu items and for scrolling through information displays
Internal memory for independent logging of 200 hours.
Easy storage of preferred measurement settings.
Passage / conductance / capacity
Weight 0.87 kg
Dimensions: W 222 mm x H 102 mm x D 60 mm
Lifetime guarantee

Technical Data

Analogue segment display:	Yes
Article number:	3947812
Backlight:	Yes
Basic precision:	0,05 %
Capacity measuring range:	1 nF - 100 mF
Current measuring range AC/DC:	500µA - 10A
Data memory / logger:	Yes / Yes
Dimensions (L x W x H) (mm):	222 x 102 x 60
Diode test / continuity test:	Yes / Yes
Display Hold / Auto-Hold:	Yes / Yes
Display resolution:	50000
Electrical safety:	CAT III 1000 V, CAT IV 600 V
Frequency measuring range:	99,99 Hz - 999,99 kHz
Interfaces:	None
Min. / Max. Recording:	Yes / Yes
Model:	FLUKE-289/FVF/EUR
Number of positions:	4.5
Resistance measuring range:	500 Ω - 500 MΩ
Temperature measurement ( PT100 / Type K / Type J):	-200°C - +1350°C
True effective measurement TRMS:	Yes
Voltage measuring range AC/DC:	50 mV - 1000 V
Warranty (years):	10
Weight (kg):	0.8709

Description

289 / FVF | Multimeter, set, 4 1/2 digits, 289, FlukeView Forms software and cables

Increase your productivity with the combo kit with Fluke 289 and FlukeView Forms. With built-in data logger functionality and TrendCapture, the 289 multimeter helps you get to the bottom of elusive intermittent problems or monitor devices while you are doing other tasks. With the FlukeView Forms software, you can overlay logged data from six measuring devices or six time periods in order to search for correlations between several events or to monitor states. Use your data to develop meaningful graphical representations and tables for professional reports, or document, save and analyze entire series of measurements.

The 289 is compatible with the infrared interface ir3000 FC. This allows you to share measurements in real time using the Fluke Connect Mobile app on your iOS or Android device. The Combo Kit with Fluke 289 and FVF offers a practical and affordable solution for preventive maintenance.

Lieferumfang

Multimeter Fluke 289
FlukeView® Forms software and interface cables
USB cable
Thermocouple probe 80BK-A
Test leads
Alligator clips
battery
Carrying bag C280
Magnetic holder
operation manual

Accessoires (1 products)

Accessoires (1 product)

FLUKE
FLUKE TP912

Replacement tips for TL910

Delivery time upon request

On Request

About the Manufacturer

FLUKE

Since its founding in 1948, Fluke has provided professional tools and measurement equipment for the installation, maintenance and service of electronic equipment in industry, power, medical, building services and electrical installations, as well as in precision measurement and quality assurance.
