FLUKE 1663DE | Multifunctional installation tester with RCD type B VDE0100 test device, memory, interface

Manufacturer number: FLK-1663 DE

1663DE
1663DE
1663DE
1663DE
1663DE
1663DE
1663DE
1663DE
1663DE
1663DE
3 in stock. Ready to ship in 1 business day

On Request

%
or choose one of the following options:
Request a quote Product is already in cart Product downloads Product inquiries Request education-price
Highlights Documents / Downloads Description Scope Related Articles

Fluke 1663DE | Multifunctional installation tester VDE0100. The ideal test device for professionals.

  • Continuity at the inputs LN, N-PE
  • Testing of DC-sensitive RCDs (type B)
  • Earth resistance
  • Voltage and frequency
  • Polarity tester, detects interrupted neutral conductors
  • Insulation resistance
  • Continuity and resistance
  • Measure motor windings with continuity test
  • Loop and line impedance
  • Estimated earth fault current (PEFC / IK)
  • Expected short circuit current (PSC / IK)
  • RCD trip out time
  • Tripping current of the RCD (ramp test)
  • Measures the tripping time and the tripping current for RCD type A and AC in a single test
  • Variable test current for RCDs
  • Automatic test sequence for residual current devices (RCDs)
  • Rotating field direction indicator
  • Automatic start that can be switched on and off for RCD and loop impedance measurement
  • Self test
  • Illuminated display
  • Storage interface
  • Z-max memory
  • Storage
  • PC interface (when used with optional FlukeView and Fluke DMS software)
  • Time and date (when used with optional FlukeView software)
  • Withstands a fall from a height of 1 meter

Documents & Downloads

Brochure
pdf | 1.41 MB
Datasheet
pdf | 1.12 MB
User report
pdf | 0.59 MB
Userguide
pdf | 2.11 MB

Description

1663DE | Multifunctional installation tester with RCD type B VDE0100 test device, memory, interface

This device is perfect for professional users because it offers a full range of functions, advanced measurement functions and is still easy to use. It has an intuitive operation that is easy to understand and use.

The Fluke 1663 empowers you with the ability to quickly and effectively verify that electrical systems are complying with local standards and regulations and to protect equipment that is inadvertently connected to systems under test.

Lieferumfang

  • Robust mains measuring lead
  • Hard case
  • Probe head with trigger button
  • Zero adapter
  • Compact, light (less than 1.3 kg), with an additional padded shoulder strap that keeps your hands free and thus facilitates all-day measuring work
