Teledyne FLIR T865 | Thermal imaging camera 640x480px, 24°+14°+42° optical viewfinder, MSX, GPS, UltraMAX, Thermal Studio (892060201)

Name: T865 | Thermal imaging camera 640x480px, 24°+14°+42° optical viewfinder, MSX, GPS, UltraMAX, Thermal Studio (892060201)
Brand: Teledyne FLIR
SKU: 892060201
Price: 33099.0 EUR
Availability: OutOfStock

Manufacturer number: 892060201

Delivery time upon request

€33,099.00

or choose one of the following options:

Product inquiries Request education-price

Teledyne FLIR 892060201 | T865 thermal imaging camera 640 x 480 px, 14 ° + 24 ° + 42 ° optics viewfinder, MSX, GPS, UltraMAX, Thermal Studio.

Display: 4 inches, 640 × 480 pixels, touchscreen LCD with autorotation
IR resolution: 640 × 480 pixels (307,200 pixels, 1,228,800 with UltraMax)
Digital camera: 5 MP with LED lamp
Color palettes: Iron, Rainbow, Rainbow HC, White hot, Black hot, Arctic, Lava
Picture modes: Infrared, Visual, MSX, Picture in Picture
Detector pitch: 12 μm
Temperature range: -40 ° C - 120 ° C || 0 ° C - 650 ° C || 300 ° C - 2,000 ° C
Digital zoom: 1 - 8 x continuously
Accuracy: from ± 1 ° C / ± 1%
Thermal sensitivity / NETD:
Spectral range: 7.5 - 14.0 μm
Image repetition: 30 Hz
Automatic lens recognition
F number: f / 1.1 (42 ° lens), f / 1.3 (24 ° lens), f / 1.5 (14 ° lens), f / 1.35 (6 ° lens)
FLIR inspection route
Voice recording: up to 60 seconds
Text input
Image Sketch
GPS tagging
METERLiNK
Storage: SD card
Image format: JPEG
Time Lapse: up to 24 hours
Battery: Li-Ion
Weight (including battery): 1.4 kg
Dimensions (L x W x H): 164.3 × 201.3 × 84.1 mm

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Article number:	892060201
Model:	T865 14°+24°+42°
Resolution in pixels:	640 x 480
Temperature measuring points:	307200
Thermal sensitivity (mK):	50

Description

T865 | Thermal imaging camera 640x480px, 24°+14°+42° optical viewfinder, MSX, GPS, UltraMAX, Thermal Studio (892060201)

The FLIR thermal imaging camera T865 of the FLIR T800 series enables non-contact inspections thanks to the swiveling lens. Assess the condition of critical electrical and mechanical devices safely and conveniently. Advanced functions such as the 1-touch level / span contrast enhancement and the sharp, laser-assisted autofocus ensure that the camera always takes exact temperature measurements.

The thermal imager T865 offers a temperature measurement accuracy of up to ± 1 ° C / ± 1%. The cameras of the T800 series are compatible with the FLIR AutoCal interchangeable lenses, for example to simplify the transition from scanning large areas with the 42 ° lens to inspecting distant targets with the 6 ° telephoto lens.

Product features:

Develop inspection routes and download them to the camera via the FLIR Route Creator to optimize the inspection of critical assets
Collect temperature data as well as thermal and visual images in a logical order for faster preventive / predictive maintenance
Automate data management and reporting by simply transferring organized files to FLIR Thermal Studio
Use the camera in any environment - the 4 inch color LCD display and the integrated eyepiece viewfinder are also ideal for working in bright sunlight
Thanks to the optics that can be rotated by 180 ° and the ergonomic design, you can easily capture targets overhead or in areas that are difficult to access
Capture smaller targets precisely, even over longer distances, by combining the high-resolution IR sensor with the optional 6 ° telephoto lens
Ensure precise measurements with laser-assisted autofocus, 1-touch level / span and extremely precise temperature accuracy
Eliminate inspection errors with industry-leading image clarity from FLIR Vision Processing, which combines MSX, UltraMax and proprietary adaptive filtering algorithms
Streamline workflow with reporting features like built-in voice annotation, customizable work folders, and Wi-Fi syncing with FLIR mobile apps
