Chroma 63113A | Electronic load module LED simulator for 631xA, 300V / 20A, 300W

Manufacturer number: 63113A

Chroma 63113A | Electronic load module LED simulator, 300V / 20A, 300W for mainframe 6312A / 6314A.

  • Special LED mode for LED power driver testing
  • Programmable dynamic resistance for LED (Rd)
  • Programmable internal resistance (Rr) for simulation of the LED ripple current
  • Fast response for PWM dimming test
  • Up to 8 channels in one mainframe
  • 16-bit precise voltage and current measurement with dual range
  • Comprehensive protection: OC, OP, OT protection and OV alarm
  • Dimensions: Height: 172 mm x width: 82 mm x depth: 489.5 mm
  • Slot width: 1 slot
  • Weight: 4.2 kg
  • Warranty: 2 years

Independant Consulting

More than 25 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Documents & Downloads

Description

63113A | Electronic load module LED simulator for 631xA, 300V / 20A, 300W

The 63113A load module is used to simulate LED loads. By setting the output voltage and the current of the LED driver, the equivalent load can simulate the load characteristic of LEDs. The forward voltage and operational stability of LEDs can be adjusted for further adjustment of the load and ripple current in order to better simulate LED characteristics.
