Benning IT105 | Installation tester / test device, VDE 0100/0105, FI test RCD (044105)
Manufacturer number: 044105
€810.00
Technical Data
All-current sensitive RCDs type B, B+: | No |
---|---|
Article number: | 044105 |
Automatic test sequence: | Nein |
Check residual voltage: | Nein |
Counter start-up: | Nein |
DIN VDE 0100 / IEC 60364-6: | Ja |
Dimensions (L x W x H) (mm): | 115 x 230 x 103 |
Insulation measurement 50V: | Nein |
Insulation measurement 100V: | Nein |
Insulation measurement 250V: | Ja |
Insulation measurement 325V: | Nein |
Insulation measurement 500V: | Ja |
Insulation measurement 1000V: | Ja |
Interfaces: | No |
Measured value memory: | No |
Mobile: | Ja |
Model: | Benning IT 105 |
Rotating field direction: | Ja |
Selective, SRCDs, PRCDs, type G/R: | No |
Stationary: | Nein |
Touch Display: | Nein |
Voltage drop: | Nein |
Weight (kg): | 1.5 |
e-Mobility (prepared): | Nein |
Documents & Downloads
Detaildescription
IT105 | Installation tester / test device, VDE 0100/0105, FI test RCD (044105)
The Benning installation tester IT105 enables you to carry out a simple and efficient safety test on electrical systems after installation, modification or as a regular repeat test in accordance with VDE0100 / 0105.
The installation tester is very easy to use: all measuring functions can be selected directly using the rotary switch. The large graphic display (95 x 55 mm) with backlighting makes operation easier and is very easy to read even in dark environments.
The Benning IT 105 has an AUTO start function for low-resistance, loop and line impedance measurements as well as a LOCK function for continuous measurements of the insulation resistance. The measuring process can be started directly using the test button on the test probe.
Measurement functions:
- Low resistance of protective conductor and equipotential bonding connections (test current: 200 mA)
- Insulation resistance with test voltage of 250 V, 500 V and 1000 V
- Loop impedance (L-PE) without FI / RCD tripping (NO-TRIP) with simultaneous display of the fault current (PFC)
- Line impedance (LN / L) with high test current (HIGH CURRENT) with simultaneous display of short-circuit current (PSC)
- Testing of RCDs, standard and delayed (S) with sinusoidal (AC) and pulsating test current (A)
- Automatic measurement of the tripping time (½ x, 1 x and 5 x IΔN) and the tripping current using the ramp method
- Voltage and frequency measurement up to 440 V.
- Three-phase direction test in three-phase networks (L1-L2-L3)
Lieferumfang
- Hard case
- Test tip with TEST button
- Probe / crocodile clip set
- Test lead with safety plug
- Shoulder strap
- 6 x 1.5 V mignon batteries
- Calibration certificate
