B&K Precision 9132C | DC Power Supply Unit, 3 Channel, Programmable, 2 x 60 V / 1 x 5 V, 3 x 3A, 375 W, USB, RS-232, 9130C Series

Manufacturer number: BK9132C

9132C
9132C
9132C
9132C
Delivery time upon request

€1,750.00

or choose one of the following options:
Request a quote Product is already in cart Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Related Articles

B&K Precision 9132C | DC power supply unit, 3 channel, programmable, 2 x 60 V / 1 x 5 V, 3 x 3A, 375 W, USB, RS-232.

Technical Data

Documents & Downloads

Datasheet
pdf | 1.84 MB

Description

9132C | DC Power Supply Unit, 3 Channel, Programmable, 2 x 60 V / 1 x 5 V, 3 x 3A, 375 W, USB, RS-232, 9130C Series

The 9132C is the most powerful model within the 9130C series from B&K Precision and is aimed at users with increased voltage requirements. The two main channels deliver up to 60 V, while the third channel with up to 5 V remains ideal for logic-related applications. The galvanically isolated outputs, precise control technology and diverse combination options make this power supply unit the ideal choice for demanding applications in research, development, power electronics and industrial test benches. The device can be conveniently remote-controlled or integrated into automated test systems via USB or RS232.

Product features:

  • 3 independent, isolated outputs (2 x 0-60 V / 3 A, 1 x 0-5 V / 3 A)
  • Total power: 375 W
  • Resolution: 1 mV / 1 mA
  • Programming and reading accuracy: up to ±0.03% + 10 mV (voltage), ±0.1% + 5 mA (current)
  • Series and parallel operation for voltage or current increase
  • Tracking mode for synchronous control of multiple channels
  • Timer function: 0.1 - 99999.9 seconds
  • Memory: 4 groups with 9 storable configurations each
  • Interfaces: USB (USBTMC), RS232, SCPI compatible
  • Dimensions: 214.5 x 88.2 x 445 mm (W x H x D)
  • Weight: 15 kg

The 9132C stands out from the other models in the series thanks to its extended voltage range of up to 60 V on the main channels. In comparison, the 9130C offers a maximum of 30 V at 3 A and the 9131C also offers 30 V, but with an increased current of 6 A. The 9132C is therefore predestined for applications with higher voltage requirements at a constant current. Despite these differences, all models have the same controls, interfaces and operating modes and can be flexibly integrated into a wide range of working environments.
